20ＧＨｚ Microwave UP/Down Converter (MC1504UDP Technical Data Sheet)

FEATURES :
* Up conversion or Down conversion * External Reference LO Frequency * Low cost and small size. * SMA Female Connector
* Operating Temperature : -40℃ to +85℃ * Separated DC Voltage 8VDC

2. APPLICATIONS :
* Test Instrumentation * Dielectric Resonator Oscillator * Low VSWR 2.5:1 MAX * Low Phase Noise * Internal Voltage Regulator

3. DESCRIPTION :
MC1504UDP is utilizes latest MMIC technology to provide a highly stable, low noise signal source (DRO), a mixer and a power amplifier or LNA in one small compact package.
MC1504UDP is designed to solve the matching issues of LO, MIXER and AMPLIFIER together. All these components are internally matched to save time, space and cost for end-users. LO frequency up to 20 GHz (fundamental), and harmonically balanced mixers used for higher frequencies

---







製作例の説明

本コンバーターはRF15GHｚをIF4.5GHｚ帯に変換し、さらに4.5GHｚIFをRF15GHｚに再変換し中継に利用している例です。RF周波数は10～20GHｚで任意に選定可能です。（LOはDRO発振器利用）

---

---
